Innolux M215HJJ-P02 bileog sonraí, sonraíocht, stoic, feidhmchlár www.looklcd-ie.com

M215HJJ-P02


Branda
Innolux
Méid
21.5
Iarratas
DMPC
Rún
1920×1080
Comhdhéanamh
CELL
Gile
0
CR
3000:1
Dathanna
16.7M
Cúlsolas
No B/L
Comhéadan
LVDS
In Stock
11446
Sonraíochtaí

Uimhir Pháirt M215HJJ-P02
BrandaInnolux
Méid21.5
IarratasDMPC
Rún1920×1080
ComhdhéanamhCELL
Gile0
CR3000:1
Dathanna16.7M
CúlsolasNo B/L
ComhéadanLVDS
branda painéilINNOLUX
múnla painéilM215HJJ-P02
cineál painéil a-Si TFT-LCD , CELL
méid an phainéil21.5 inch
taifeach1920(RGB)×1080 , FHD
mód taispeánaMVA, Normally Black, Transmissive
limistéar gníomhach476.064×267.786 mm
imlíne487.664×279.286 mm
dromchlaAntiglare (Haze 25%), Hard coating (3H)
doimhneacht gloine0.50+0.50 mm
transmissivity4.46% (Typ.)(with Polarizer)
cóimheas codarsnachta3000:1 (Typ.)
dathanna a thaispeáint16.7M (8-bit), CIE193172%
am freagartha20/5 (Typ.)(Tr/Td)
uillinn féachana89/89/89/89 (Typ.)(CR≥20)(L/R/U/D)
minicíocht60Hz
comhéadan comharthaLVDS (2 ch, 8-bit), 30 pins
voltas ionchuir5.0V (Typ.)
iarratasDMPC
