| Uimhir Pháirt | LQ170E1LG18 |
| Branda | SHARP |
| Méid | 17.0 |
| Iarratas | DMPC |
| Rún | 1280×1024 |
| Comhdhéanamh | LCM |
| Gile | 300 |
| CR | 450:1 |
| Dathanna | 16.2M |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | SHARP |
| múnla painéil | LQ170E1LG18 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 17.0 inch |
| taifeach | 1280(RGB)×1024 , SXGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 337.92×270.336 mm |
| imlíne | 358.5×296.5×17.5 mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 300 cd/m² (Typ.) |
| cóimheas codarsnachta | 450:1 (Typ.) |
| dathanna a thaispeáint | 16.2M (6-bit + FRC) |
| am freagartha | 16 (Typ.)(Tr+Td) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 4 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (2 ch, 8-bit), 30 pins |
| voltas ionchuir | 5.0V (Typ.) |
| rohs: | |
| iarratas | DMPC |
| B170PW02 V0 | AUO | 17.0 | 1440×900 |
| LC170WXN-SAA1 | LG Display | 17.0 | 1366×768 |
| LQ170E1LG11 | SHARP | 17.0 | 1280×1024 |
| LQ170E1LG18 | SHARP | 17.0 | 1280×1024 |
| LQ170E1LG21 | SHARP | 17.0 | 1280×1024 |
| LQ170K1LW02 | SHARP | 17.0 | 1280×768 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LQ170M1LA4B | SHARP | 17.0 | 1920×1200 |
| LTM170E8-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| HT185WX1-100 | BOE | 18.5 | 1366×768 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LM240WU8-SLD4 | LG Display | 24.0 | 1920×1200 |
| LM260WU2-SLA2 | LG Display | 25.5 | 1920×1200 |
| LTM200KT10 | Samsung | 20.0 | 1600×900 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| M170ETN01.0 | AUO | 17.0 | 1280×1024 |
| M190A1-L0A | Innolux | 19.0 | 1440×900 |
| M220Z3-LA3 | Innolux | 22.0 | 1680×1050 |
