Innolux M215H3-LA1 bileog sonraí, sonraíocht, stoic, feidhmchlár www.looklcd-ie.com

M215H3-LA1


Branda
Innolux
Méid
21.5
Iarratas
DMPC
Rún
1920×1080
Comhdhéanamh
LCM
Gile
250
CR
1000:1
Dathanna
16.7M
Cúlsolas
WLED
Comhéadan
LVDS
In Stock
10
Sonraíochtaí

Uimhir Pháirt M215H3-LA1
BrandaInnolux
Méid21.5
IarratasDMPC
Rún1920×1080
ComhdhéanamhLCM
Gile250
CR1000:1
Dathanna16.7M
CúlsolasWLED
ComhéadanLVDS
branda painéilCMO
múnla painéilM215H3-LA1
cineál painéil a-Si TFT-LCD , LCM
méid an phainéil21.5 inch
taifeach1920(RGB)×1080 , FHD
mód taispeánaTN, Normally White, Transmissive
limistéar gníomhach476.64×268.11 mm
imlíne495.6×292.2×12.1 mm
dromchlaAntiglare (Haze 25%), Hard coating (3H)
gile250 cd/m² (Typ.)
cóimheas codarsnachta1000:1 (Typ.)
dathanna a thaispeáint16.7M (8-bit)
am freagartha1.3/3.7 (Typ.)(Tr/Td)
uillinn féachana85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
minicíocht60Hz
cineál lampa13S6PWLEDWithout Driver
comhéadan comharthaLVDS (2 ch, 8-bit), 30 pins
voltas ionchuir5.0V (Typ.)
iarratasDMPC
