| Uimhir Pháirt | LQ170M1LA4B |
| Branda | SHARP |
| Méid | 17.0 |
| Iarratas | NBPC |
| Rún | 1920×1200 |
| Comhdhéanamh | LCM |
| Gile | 340 |
| CR | 450:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | SHARP |
| múnla painéil | LQ170M1LA4B 1 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 17.0 inch |
| taifeach | 1920(RGB)×1200 , WUXGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 365.76×228.6 mm |
| imlíne | 382.2×248×7 mm |
| stíl cruth | Wedge (PCBA Bent, Depth ≥5.2mm) |
| dromchla | Glare (Haze 0%), Hard coating (2H), Antireflection |
| gile | 340 cd/m² (Typ.) |
| cóimheas codarsnachta | 450:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193172% |
| am freagartha | 30 (Typ.)(Tr+Td) |
| uillinn féachana | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 2 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (2 ch, 6-bit), 30 pins |
| voltas ionchuir | 3.3V (Typ.) |
| rohs: | |
| iarratas | NBPC |
