| Uimhir Pháirt | AM-1024600K5TMQW-01H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial Outdoor H |
| Rún | 1024×600 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 700:1 |
| Dathanna | 16.7M |
| Cúlsolas | 8S3P |
| Comhéadan | LVDS |
| monaróir | AMPIRE |
| méid scáileáin | 7.0 inch |
| uimhir picteilín | 1024(RGB)×600 (WSVGA) 169PPI |
| limistéar gníomhach(mm) | 153.6 × 90 (H×V) |
| limistéar bezel (mm) | 156.2 × 92.6 (H×V) |
| luminance | 1000 cd/m² (Typ.) |
| uillinn féachana | 75/75/70/75 (Typ.)(CR≥10) |
| radharc maith ag | - |
| doimhneacht dath | 16.7M |
| mais | TBD |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (1 ch, 8-bit) , 20 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ainm samhail | AM-1024600K5TMQW-01H |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 165.5 × 104.44 × 9.46 (H×V×D) |
| cóireáil | Glare (Haze 0%), Hard coating |
| cóimheas codarsnachta | 700 : 1 (Typ.) (TM) |
| freagra | 20/20 (Typ.)(Tr/Td) ms |
| modh oibre | TN, Normally White, Transmissive |
| cúlsolas | 8S3P WLED , 50K hours , With LED Driver |
| a úsáidtear le haghaidh | Industrial Outdoor High Brightness |
| scáileán tadhaill | Without |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| CLAA070NC0BCT | CPT | 7.0 | 1024×600 |
| CLAA070NP01HXG | CPT | 7.0 | 1024×600 |
| COM70T7M17ZLC | ORTUSTECH | 7.0 | 800×480 |
| LW700AT9009 | Innolux | 7.0 | 800×480 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
