| Uimhir Pháirt | COM70T7M17ZLC |
| Branda | ORTUSTECH |
| Méid | 7.0 |
| Iarratas | IA |
| Rún | 800×480 |
| Comhdhéanamh | LCM |
| Gile | 530 |
| CR | 400:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | TTL |
| branda painéil | ORTUSTECH |
| múnla painéil | COM70T7M17ZLC |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 7.0 inch |
| taifeach | 800(RGB)×480 , WVGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 152.4×91.44 mm |
| imlíne | 165×105.8×3.65 mm |
| dromchla | Hard coating (3H) |
| gile | 530 cd/m² (Typ.) |
| cóimheas codarsnachta | 400:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit) |
| am freagartha | 40/60 (Max.)(Tr/Td) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 8S3PWLEDWithout Driver |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | IA |
