| Uimhir Pháirt | AM-1024600KTMQW-01H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | IA |
| Rún | 1024×600 |
| Comhdhéanamh | LCM |
| Gile | 1000 |
| CR | 700:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| múnla painéil | AM-1024600KTMQW-01H |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 7.0 inch |
| taifeach | 1024(RGB)×600 , WSVGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 153.6×90 mm |
| imlíne | 165.5×104.44×7.91 mm |
| dromchla | Glare (Haze 0%), Hard coating |
| gile | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 700:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (8-bit) |
| am freagartha | 10/15 (Typ.)(Tr/Td) |
| uillinn féachana | 75/75/70/75 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 8S3PWLEDEmbedded (LED Driver) |
| comhéadan comhartha | LVDS (1 ch, 8-bit), 20 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | IA |
