| Uimhir Pháirt | WEF012864QS |
| Branda | Winstar |
| Méid | 2.7 |
| Iarratas | Home Appliance Handh |
| Rún | 128×64 |
| Comhdhéanamh | PM-OLED , OLED |
| Gile | |
| CR | |
| Dathanna | Mono(Blue) |
| Cúlsolas | self |
| Comhéadan | 8-bit |
| branda painéil | Winstar |
| méid an phainéil | 2.7" |
| taifeach | 128×64, 52PPI |
| limistéar taispeána | 61.41(W)×30.69(H) mm |
| méid imlíne | 89.7(W)×47.2(H) mm |
| uillinn féachana | - |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | Mono(Blue) |
| minicíocht | - |
| Tiománaí ic | COG Built-in SSD1309ZC |
| meáchan painéal | - |
| comhéadan comhartha | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 30 pins FPC |
| voltas ionchuir | 3.0/13V (Typ.)(VDD/VCC) |
| timpeallacht | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C |
| múnla painéil | WEF012864QS |
| cineál painéil | PM-OLED , OLED |
| formáid picteilín | Rectangle |
| oscailt bezel | 63.41(W)×32.69(H) mm |
| dromchla | - |
| mód taispeána | - |
| am freagartha | - |
| cineál lampa | self |
| scáileán tadhaill | Without |
| iarratas | Home Appliance Handheld & PDA Healthcare Instruments & Meters |
