| Uimhir Pháirt | WEA012864DWPP3N00001 |
| Branda | Winstar |
| Méid | 0.96 |
| Iarratas | Instruments & Me |
| Rún | 128×64 |
| Comhdhéanamh | PM-OLED, OLED |
| Gile | |
| CR | |
| Dathanna | Mono(White) |
| Cúlsolas | self |
| Comhéadan | 4-wire |
| branda | Winstar |
| Mionsamhail | WEA012864DWPP3N00001 |
| méid trasnánach | 0.96 inch |
| cineál | PM-OLED, OLED |
| formáid picteilín | 128×64 149PPI |
| cumraíocht | Rectangle |
| limistéar gníomhach | 21.74(H)×10.86(V) mm |
| imlíne dim. | 38(H)×28.5(V) ×4.37(D) mm |
| limistéar bezel | 23.94(H)×12.06(V) mm |
| cóireáil | - |
| treo amharc | Symmetry |
| am freagartha | - |
| uillinn féachana | - |
| modh oibriúcháin | - |
| dath tacaíochta | Mono(White) |
| foinse solais | self |
| meáchan | - |
| deartha le haghaidh | Instruments & Meters |
| ráta fhráma | - |
| painéal tadhaill | Without |
| sonraí d-ic | COG Built-in SSD1306BZ |
| cineál comhéadan | 4-wire SPI, I²C , 8 pins PIN |
| soláthar leictreachas | 3.3/5.0/7.5V (Typ.) |
| timpeallacht | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
