| Uimhir Pháirt | WEA012864DLPP3N00001 |
| Branda | Winstar |
| Méid | 0.96 |
| Iarratas | Instruments & Me |
| Rún | 128×64 |
| Comhdhéanamh | PM-OLED, OLED |
| Gile | |
| CR | |
| Dathanna | Mono(Yellow) |
| Cúlsolas | self |
| Comhéadan | 4-wire |
| branda painéil | Winstar |
| múnla painéil | WEA012864DLPP3N00001 |
| méid an phainéil | 0.96" |
| cineál painéil | PM-OLED, OLED |
| taifeach | 128×64, 149PPI |
| formáid picteilín | Rectangle |
| limistéar taispeána | 21.74(W)×10.86(H) mm |
| oscailt bezel | 23.94(W)×12.06(H) mm |
| méid imlíne | 38(W)×28.5(H) ×4.37(D) mm |
| dromchla | - |
| uillinn féachana | - |
| mód taispeána | - |
| radharc is fearr ar | Symmetry |
| am freagartha | - |
| dathanna a thaispeáint | Mono(Yellow) |
| cineál lampa | self |
| minicíocht | - |
| scáileán tadhaill | Without |
| Tiománaí ic | COG Built-in SSD1306BZ |
| meáchan painéal | - |
| iarratas | Instruments & Meters |
| comhéadan comhartha | 4-wire SPI, I²C , 8 pins PIN |
| voltas ionchuir | 3.3/5.0/7.5V (Typ.) |
| timpeallacht | Operating Temp.: -40 ~ 80 °C ; Storage Temp.: -40 ~ 85 °C |
