| Uimhir Pháirt | TX20D33VM2BAC |
| Branda | KOE |
| Méid | 8.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 600:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | CMOS |
| monaróir | KOE |
| méid scáileáin | 8.0 inch |
| uimhir picteilín | 800(RGB)×480 (WVGA) 116PPI |
| limistéar gníomhach(mm) | 174 × 104.4 (H×V) |
| limistéar bezel (mm) | 187.0 × 108.4 (H×V) |
| luminance | - |
| uillinn féachana | 80/80/60/80 (Typ.)(CR≥10) |
| radharc maith ag | 6 o'clock |
| doimhneacht dath | 262K |
| mais | 160g |
| ráta athnuachana | 60Hz |
| cineál comhartha | CMOS (1 ch, 6-bit) , 40 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| ainm samhail | TX20D33VM2BAC |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 189 × 120 × 8 (H×V×D) |
| cóireáil | - |
| cóimheas codarsnachta | 600 : 1 (Typ.) (TM) |
| freagra | 20 (Typ.)(Tr+Td) ms |
| modh oibre | TN, Normally White, Transmissive |
| cúlsolas | WLED , 50K hours , No Driver |
| a úsáidtear le haghaidh | Industrial |
| scáileán tadhaill | Without |
