| Uimhir Pháirt | TV080WUM-NK0 |
| Branda | BOE |
| Méid | 8.0 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 850:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | MIPI |
| branda | BOE |
| Mionsamhail | TV080WUM-NK0 |
| méid trasnánach | 8.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1200(RGB)×1920 [WUXGA] 283PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 107.64(H)×172.224(V) mm |
| imlíne dim. | - |
| luminance | - |
| cóimheas codarsnachta | 850:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | ADS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 63% NTSC |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | Pad & Tablet |
| ráta fhráma | 60Hz |
| painéal tadhaill | - |
| cineál comhéadan | MIPI (4 data lanes) , 39 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
