| Uimhir Pháirt | TV080WUM-AK2 |
| Branda | BOE |
| Méid | 8.0 |
| Iarratas | Pad & Tablet |
| Rún | 1200×1920 |
| Comhdhéanamh | Assembly , a-Si TF |
| Gile | |
| CR | 850:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S3P |
| Comhéadan | MIPI |
| monaróir | BOE |
| ainm samhail | TV080WUM-AK2 |
| méid scáileáin | 8.0 inch |
| cineál scáileáin | Assembly , a-Si TFT-LCD |
| uimhir picteilín | 1200(RGB)×1920 (WUXGA) 283PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 107.64 × 172.224 (H×V) |
| imlíne (mm) | 122.2 × 210.95 × 3.95 (H×V×D) |
| luminance | 350 cd/m² (Typ.) |
| cóimheas codarsnachta | 850 : 1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | - |
| doimhneacht dath | 16.7M 63% NTSC |
| cúlsolas | 7S3P WLED , 15K hours , No Driver |
| mais | 130g (Max.) |
| a úsáidtear le haghaidh | Pad & Tablet |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | PCAP, Optical Bonding |
| cineál comhartha | MIPI (4 data lanes) , 39 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: -20 ~ 60 °C |
