| Uimhir Pháirt | TM050RDZG03-30 |
| Branda | TIANMA |
| Méid | 5.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | 3S6P |
| Comhéadan | |
| monaróir | TIANMA |
| ainm samhail | TM050RDZG03-30 |
| méid scáileáin | 5.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×480 (WVGA) 188PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 108 × 64.8 (H×V) |
| imlíne (mm) | 120.7 × 77.8 × 5.9 (H×V×D) |
| limistéar bezel (mm) | 111.1 × 67.9 (H×V) |
| cóireáil | Antiglare, Hard coating (3H) |
| luminance | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 600 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10) |
| freagra | 20/30 (Typ./Max.)(Tr+Td) ms |
| radharc maith ag | 12 o'clock |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 16.7M 50% NTSC |
| cúlsolas | 3S6P WLED , 50K hours |
| mais | TBD |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
