| Uimhir Pháirt | DLC0500AIG-2 |
| Branda | Other |
| Méid | 5.0 |
| Iarratas | VDP |
| Rún | 640×480 |
| Comhdhéanamh | LCM |
| Gile | 400 |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | TTL |
| branda painéil | DLC |
| múnla painéil | DLC0500AIG-2 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 5.0 inch |
| taifeach | 640(RGB)×480 , VGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 101.568×76.176 mm |
| imlíne | 117.65×88.43×6 mm |
| dromchla | Antiglare |
| gile | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193140% |
| am freagartha | 10/10 (Typ.)(Tr/Td) |
| uillinn féachana | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 3S6PWLEDWithout Driver |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltas ionchuir | 3.3V (Typ.)(VCC) |
| iarratas | VDP |
