| Uimhir Pháirt | TCG121XGLPBPNN-AN40-S |
| Branda | Kyocera |
| Méid | 12.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 600:1 |
| Dathanna | 262K/16.2M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | Kyocera |
| múnla painéil | TCG121XGLPBPNN-AN40-S |
| méid an phainéil | 12.1" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1024(RGB)×768, XGA, 105PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 245.76(W)×184.32(H) mm |
| oscailt bezel | 249.0(W)×187.5(H) mm |
| méid imlíne | 260.5(W)×203(H) ×10.9(D) mm |
| dromchla | Antiglare |
| gile | 780 cd/m² (Typ.) |
| cóimheas codarsnachta | 600:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | AWV, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 18/12 (Typ.)(Tr/Td) |
| dathanna a thaispeáint | 262K/16.2M 51% NTSC |
| cineál lampa | WLED , 50K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | 555g |
| iarratas | Industrial Outdoor High Brightness |
| comhéadan comhartha | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| AA121SJ23 | Mitsubishi | 12.1 | 800×600 |
| B121EW09 V4 | AUO | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| LQ121S1DC71 | SHARP | 12.1 | 800×600 |
| LQ121X1LH73 | SHARP | 12.1 | 1024×768 |
| LTD121C32S | TOSHIBA | 12.1 | 800×600 |
| LTD121EA3P | TOSHIBA | 12.1 | 1024×768 |
| LTD121EXPD | TOSHIBA | 12.1 | 1280×800 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
