| Uimhir Pháirt | TCG121XGLPAPNN-AN20-S |
| Branda | Kyocera |
| Méid | 12.1 |
| Iarratas | Industrial |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 750:1 |
| Dathanna | 262K/16.2M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | Kyocera |
| Mionsamhail | TCG121XGLPAPNN-AN20-S |
| méid trasnánach | 12.1 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×768 [XGA] 105PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 245.76(H)×184.32(V) mm |
| imlíne dim. | 260.5(H)×203.4(V) ×10.8(D) mm |
| limistéar bezel | 249.0(H)×187.5(V) mm |
| cóireáil | Antiglare |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 750:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 18/12 (Typ.)(Tr/Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | AWV, Normally Black, Transmissive |
| dath tacaíochta | 262K/16.2M 50% NTSC |
| foinse solais | WLED , 50K hours , With LED Driver |
| meáchan | 670g |
| deartha le haghaidh | Industrial |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
