| Uimhir Pháirt | PT236AT02-4 |
| Branda | HKC |
| Méid | 23.6 |
| Iarratas | TV Sets |
| Rún | 1366×768 |
| Comhdhéanamh | CELL , a-Si TFT-LC |
| Gile | |
| CR | 3000:1 |
| Dathanna | 16.7M |
| Cúlsolas | No |
| Comhéadan | LVDS |
| monaróir | HKC |
| méid scáileáin | 23.6 inch |
| uimhir picteilín | 1366(RGB)×768 (WXGA) 66PPI |
| limistéar gníomhach(mm) | 521.471 × 293.184 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 0 cd/m² |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| tiús gloine | 0.50+0.50 mm |
| doimhneacht dath | 16.7M 73% NTSC |
| mais | 500g (Typ.) |
| ráta athnuachana | 60Hz |
| Ic liosta tiománaí | Built-in COF 2 source + 2 gate chips |
| cineál comhartha | LVDS (1 ch, 8-bit) , 30 pins Connector |
| soláthar voltais | 12.0V (Typ.) |
| uas. rátálacha | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ainm samhail | PT236AT02-4 |
| cineál scáileáin | CELL , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 535.471 × 306.404 × 1.4 (H×V×D) |
| cóireáil | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 3000 : 1 (Typ.) (TM) |
| freagra | 9.5 (Typ.)(G to G) ms |
| modh oibre | FSA, Normally Black, Transmissive |
| transmissivity | 5.8% (Typ.)(with Polarizer) |
| cúlsolas | No B/L |
| a úsáidtear le haghaidh | TV Sets |
| scáileán tadhaill | Without |
