| Uimhir Pháirt | HM236WU3-100 |
| Branda | BOE |
| Méid | 23.6 |
| Iarratas | DMPC |
| Rún | 1920×1080 |
| Comhdhéanamh | CELL |
| Gile | 0 |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | No B/L |
| Comhéadan | LVDS |
| branda painéil | BOE |
| múnla painéil | HM236WU3-100 |
| cineál painéil | a-Si TFT-LCD , CELL |
| méid an phainéil | 23.6 inch |
| taifeach | 1920(RGB)×1080 , FHD |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 521.28×293.22 mm |
| imlíne | 535.9×307 mm |
| dromchla | Antiglare (Haze 25%), Hard coating (3H) |
| transmissivity | 5.3% (Typ.)(with Polarizer) |
| cóimheas codarsnachta | 1000:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (6-bit + Hi-FRC) |
| am freagartha | 1.5/3.5 (Typ.)(Tr/Td) |
| uillinn féachana | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| comhéadan comhartha | LVDS (2 ch, 8-bit), 30 pins |
| voltas ionchuir | 5.0V (Typ.) |
| iarratas | DMPC |
