| Uimhir Pháirt | P101DEA-AZ0 |
| Branda | Innolux |
| Méid | 10.1 |
| Iarratas | Pad & Tablet |
| Rún | 800×1280 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | 4 |
| Comhéadan | MIPI |
| monaróir | Innolux |
| ainm samhail | P101DEA-AZ0 |
| méid scáileáin | 10.1 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 800(RGB)×1280 (WXGA) 150PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 135.36 × 216.576 (H×V) |
| imlíne (mm) | 143.24 × 229.18 × 4.4 (H×V×D) |
| limistéar bezel (mm) | - |
| cóireáil | Glare (Haze 0%), Hard coating |
| luminance | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Min.)(CR≥10) |
| freagra | 35 (Max.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | AAS, Normally Black, Transmissive |
| doimhneacht dath | 16.7M 60% NTSC |
| cúlsolas | 4 strings WLED , 15K hours , No Driver |
| mais | 175g (Max.) |
| a úsáidtear le haghaidh | Pad & Tablet |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | MIPI (4 data lanes) , Connector 40 pins |
| soláthar voltais | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| uas. rátálacha | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| B101AW03 V0 | AUO | 10.1 | 1024×600 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| EJ101IA-02A | Innolux | 10.1 | 1280×800 |
| HSD101PFW3-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| LP101WH1-TLB2 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LP101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
