| Uimhir Pháirt | M090AWP4 R0 |
| Branda | IVO |
| Méid | 9.0 |
| Iarratas | Outdoor High Brightn |
| Rún | 800×480 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 700:1 |
| Dathanna | 262K |
| Cúlsolas | 8S3P |
| Comhéadan | Parallel |
| branda painéil | IVO |
| méid an phainéil | 9.0" |
| taifeach | 800(RGB)×480, WVGA, 104PPI |
| limistéar taispeána | 198(W)×112.08(H) mm |
| méid imlíne | 210.82(W)×126.96(H) ×6.4(D) mm |
| gile | 750 cd/m² (Typ.) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10) |
| radharc is fearr ar | 6 o'clock |
| dathanna a thaispeáint | 262K 70% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | 251g (Max.) |
| comhéadan comhartha | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| voltas ionchuir | 3.3/11.6/22/-7V (Typ.)(VCC/VDDA/VGH/VGL) |
| timpeallacht | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| múnla painéil | M090AWP4 R0 |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 200.2(W)×114.28(H) mm |
| dromchla | Antiglare, Hard coating (3H) |
| cóimheas codarsnachta | 700:1 (Typ.) (TM) |
| mód taispeána | TN, Normally White, Transmissive |
| am freagartha | 12 (Typ.)(Tr+Td) |
| cineál lampa | 8S3P WLED , 30K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Outdoor High Brightness Automotive Display |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| EE090NA-01C | Innolux | 9.0 | 1280×800 |
| G090VTN02.0 | AUO | 9.0 | 800×480 |
| NL8048BC24-12 | NLT | 9.0 | 800×480 |
| T-55562D090J-LW-A-AAN | Kyocera | 9.0 | 800×480 |
| TX23D85VM0BAA | KOE | 9.0 | 1280×768 |
