| Uimhir Pháirt | TX23D85VM0BAA |
| Branda | KOE |
| Méid | 9.0 |
| Iarratas | IA |
| Rún | 1280×768 |
| Comhdhéanamh | LCM |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | HITACHI |
| múnla painéil | TX23D85VM0BAA |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 9.0 inch |
| taifeach | 1280(RGB)×768 , WXGA |
| mód taispeána | IPS, Normally Black, Transmissive |
| limistéar gníomhach | 193.92×116.352 mm |
| dromchla | |
| gile | |
| cóimheas codarsnachta | 1000:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (8-bit) |
| am freagartha | |
| uillinn féachana | 85/85/85/85 (Typ.)(CR＞10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | WLEDEmbedded (LED Driver) |
| comhéadan comhartha | LVDS (1 ch, 8-bit) |
| iarratas | IA |
