| Uimhir Pháirt | M080AWT8 R1 |
| Branda | IVO |
| Méid | 8.0 |
| Iarratas | Automotive Display |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | IVO |
| Mionsamhail | M080AWT8 R1 |
| méid trasnánach | 8.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×600 [WSVGA] 148PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 176.64(H)×99.36(V) mm |
| imlíne dim. | 192.8(H)×116.9(V) ×8.35(D) mm |
| limistéar bezel | 178.84(H)×101.56(V) mm |
| cóireáil | Antiglare |
| luminance | 670 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| treo amharc | 6 o'clock |
| am freagartha | 16 (Typ.)(Tr+Td) |
| uillinn féachana | 75/75/70/75 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K/16.7M 72% NTSC |
| foinse solais | WLED [3S7P] , 30K hours , W/O Driver |
| meáchan | 240g (Max.) |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| C080VW05 V0 | AUO | 8.0 | 800×480 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| DLC0800BIG-4 | Other | 8.0 | 800×600 |
| EJ080NA-05B | Innolux | 8.0 | 800×600 |
| HJ080NA-04L | Innolux | 8.0 | 1024×768 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
| ZJ080NA-08A | Innolux | 8.0 | 1024×600 |
