| Uimhir Pháirt | LTM170E6-L04 |
| Branda | Samsung |
| Méid | 17.0 |
| Iarratas | DMPC |
| Rún | 1280×1024 |
| Comhdhéanamh | LCM |
| Gile | 250 |
| CR | 500:1 |
| Dathanna | 16.7M |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | SAMSUNG |
| múnla painéil | LTM170E6-L04 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 17.0 inch |
| taifeach | 1280(RGB)×1024 , SXGA |
| mód taispeána | PVA, Normally Black, Transmissive |
| limistéar gníomhach | 337.92×270.336 mm |
| imlíne | 358.5×296.5×17.5 mm |
| dromchla | Antiglare (Haze 44%), Hard coating (3H) |
| gile | 250 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (8-bit) |
| am freagartha | 15/10 (Typ.)(Tr/Td) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 4 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (2 ch, 8-bit), 30 pins |
| voltas ionchuir | 5.0V (Typ.) |
| iarratas | DMPC |
| LTM170E4-P01 | Samsung | 17.0 | 1280×1024 |
| LTM170E6-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170E6-L04 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L11 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EX-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| CLAA150XA03 | CPT | 15.0 | 1024×768 |
| LM151X3-C3C1 | LG Display | 15.1 | 1024×768 |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LM270WF3-TLA1 | LG Display | 27.0 | 1920×1080 |
| LQ170E1LG18 | SHARP | 17.0 | 1280×1024 |
| LTM181E4-L01 | Samsung | 18.1 | 1280×1024 |
| LTM201M2-L02 | Samsung | 20.1 | 1680×1050 |
| M170EP01 V2 | AUO | 17.0 | 1280×1024 |
| M215H1-L03 | Innolux | 21.5 | 1920×1080 |
| TM190MCS02 | Tianma | 19.0 | 1440×900 |
