| Uimhir Pháirt | LP156WHU-TPD1 |
| Branda | LG Display |
| Méid | 15.6 |
| Iarratas | NBPC |
| Rún | 1366×768 |
| Comhdhéanamh | LCM |
| Gile | 200 |
| CR | 350:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda painéil | LG Display |
| múnla painéil | LP156WHU-TPD1 8 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 15.6 inch |
| taifeach | 1366(RGB)×768 , WXGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 344.232×193.536 mm |
| imlíne | 359.5×223.5×3.2 mm |
| stíl cruth | Slim (PCBA Flat, Depth ≤3.2mm) |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 200 cd/m² (Typ.) |
| cóimheas codarsnachta | 350:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193145% |
| am freagartha | 16 (Typ.)(Tr+Td) |
| uillinn féachana | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | WLEDEmbedded (LED Driver) |
| comhéadan comhartha | eDP (1 Lane), 30 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | NBPC |
