| Uimhir Pháirt | LTN154P1-L03 |
| Branda | Samsung |
| Méid | 15.4 |
| Iarratas | NBPC |
| Rún | 1680×1050 |
| Comhdhéanamh | LCM |
| Gile | 185 |
| CR | 300:1 |
| Dathanna | 262K |
| Cúlsolas | CCFL |
| Comhéadan | LVDS |
| branda painéil | SAMSUNG |
| múnla painéil | LTN154P1-L03 2 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 15.4 inch |
| taifeach | 1680(RGB)×1050 , WSXGA+ |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 331.38×207.11 mm |
| imlíne | 344×222×6.5 mm |
| stíl cruth | Wedge (PCBA Bent, Depth ≥5.2mm) |
| dromchla | Glare (Haze 0%), Hard coating (3H) |
| gile | 185 cd/m² (Typ.) |
| cóimheas codarsnachta | 300:1 (Typ.) |
| dathanna a thaispeáint | 262K (6-bit), CIE193145% |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 1 pcsCCFLWithout Driver |
| comhéadan comhartha | LVDS (2 ch, 6-bit), 30 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | NBPC |
