| Uimhir Pháirt | LA090WH1-SL01 |
| Branda | LG Display |
| Méid | 9.0 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | LG Display |
| Mionsamhail | LA090WH1-SL01 |
| méid trasnánach | 9.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1280(RGB)×720 [WXGA] 164PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 200.448(H)×106.056(V) mm |
| imlíne dim. | 213.2(H)×121.2(V) ×8.6(D) mm |
| limistéar bezel | 203.148(H)×108.756(V) mm |
| cóireáil | Antiglare |
| luminance | 600 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 17/13 (Max.)(Tr/Td) |
| uillinn féachana | 80/80/80/80 (Min.)(CR≥10) |
| modh oibriúcháin | IPS, Normally Black, Transmissive |
| dath tacaíochta | 16.7M 65% NTSC |
| foinse solais | WLED [6S3P] , 10K hours , W/O Driver |
| meáchan | 219/224g (Typ./Max.) |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 60 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -40 ~ 95 °C |
