| Uimhir Pháirt | KCG057QV1DL-G770 |
| Branda | Kyocera |
| Méid | 5.7 |
| Iarratas | Industrial |
| Rún | 320×240 |
| Comhdhéanamh | CSTN-LCD, LCM |
| Gile | |
| CR | 55:1 |
| Dathanna | Color |
| Cúlsolas | CCFL |
| Comhéadan | Parallel |
| branda | Kyocera |
| Mionsamhail | KCG057QV1DL-G770 |
| méid trasnánach | 5.7 inch |
| cineál | CSTN-LCD, LCM |
| formáid picteilín | 320(RGB)×240 [QVGA] 70PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 115.2(H)×86.4(V) mm |
| imlíne dim. | 144(H)×104.8(V) ×15.3(D) mm |
| limistéar bezel | 119.4(H)×90.6(V) mm |
| cóireáil | Hard coating (2H) |
| luminance | - |
| cóimheas codarsnachta | 55:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 180/170 (Typ.)(Tr/Td) |
| uillinn féachana | 50/50/20/35 (Typ.)(CR≥2) |
| modh oibriúcháin | STN, Normally Black, Transmissive |
| dath tacaíochta | Color |
| foinse solais | CCFL [1 pcs] |
| meáchan | 220g (Typ.) |
| deartha le haghaidh | Industrial |
| ráta fhráma | 75Hz |
| painéal tadhaill | 4-wire Resistive Touch |
| cineál comhéadan | Parallel Data (1ch, 8-bit) Connector |
| soláthar leictreachas | 3.3/5.0V (Typ.)(VDD) |
| timpeallacht | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
