| Uimhir Pháirt | KCG057QV1DB-G760 |
| Branda | Kyocera |
| Méid | 5.7 |
| Iarratas | IA |
| Rún | 320×240 |
| Comhdhéanamh | LCM |
| Gile | 380 |
| CR | 40:1 |
| Dathanna | Color |
| Cúlsolas | CCFL |
| Comhéadan | Parallel Data |
| branda painéil | Kyocera |
| múnla painéil | KCG057QV1DB-G760 |
| cineál painéil | CSTN-LCD , LCM |
| méid an phainéil | 5.7 inch |
| taifeach | 320(RGB)×240 , QVGA |
| mód taispeána | STN, Normally Black, Transmissive |
| limistéar gníomhach | 115.2×86.4 mm |
| imlíne | 144×104.8×13.2 mm |
| dromchla | Glare (Haze 0%) |
| gile | 380 cd/m² (Typ.) |
| cóimheas codarsnachta | 40:1 (Typ.) |
| dathanna a thaispeáint | Color |
| am freagartha | 250/200 (Typ.)(Tr/Td) |
| uillinn féachana | 50/50/50/70 (Typ.)(CR≥2)(L/R/U/D) |
| minicíocht | 75Hz |
| cineál lampa | 1 pcsCCFLOptional |
| comhéadan comhartha | Parallel Data (8-bit), 20 pins |
| voltas ionchuir | 3.3/5.0V (Typ.)(VDD) |
| iarratas | IA |
