| Uimhir Pháirt | HGS128647-Y-EH-LV |
| Branda | Other |
| Méid | 1.54 |
| Iarratas | IA |
| Rún | 128×64 |
| Comhdhéanamh | OLED |
| Gile | 150 |
| CR | 2000:1 |
| Dathanna | Mono(Yellow) |
| Cúlsolas | self |
| Comhéadan | CPU/SPI/I²C |
| branda painéil | TSINGTEK |
| múnla painéil | HGS128647-Y-EH-LV |
| cineál painéil | PM-OLED , OLED |
| méid an phainéil | 1.54 inch |
| taifeach | 128×64 |
| limistéar gníomhach | 35.056×17.52 mm |
| imlíne | 54×39.5×8.5 mm |
| dromchla | |
| gile | 150 cd/m² (Typ.) |
| cóimheas codarsnachta | 2000 : 1 (Min.) |
| dathanna a thaispeáint | Mono(Yellow) |
| uillinn féachana | 80/80/80/80 (Min.)(L/R/U/D) |
| Tiománaí ic | Built-in SSD1305 |
| comhéadan comhartha | 8-bit 6800/8080 parallel, 4-wire SPI, I²C, 20 pins |
| voltas ionchuir | 3.3V (Typ.) |
| rohs: | |
| iarratas | IA |
