| Uimhir Pháirt | G070VAN01.1 |
| Branda | AUO |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 800×480 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1300:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 7S2P |
| Comhéadan | LVDS |
| monaróir | AUO |
| méid scáileáin | 7.0 inch |
| uimhir picteilín | 800×480(RGB) (WVGA) 133PPI |
| limistéar gníomhach(mm) | 152.4 × 91.44 (H×V) |
| limistéar bezel (mm) | 154.2 × 93.24 (H×V) |
| luminance | 200 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 262K/16.7M 60% NTSC |
| mais | 160g (Typ.) |
| ráta athnuachana | 60Hz |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ainm samhail | G070VAN01.1 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Horizontal Stripe |
| imlíne (mm) | 166.6 × 107 × 10 (H×V×D) |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 1300 : 1 (Typ.) (TM) |
| freagra | 11/19 (Max.)(Tr/Td) ms |
| modh oibre | AHVA, Normally Black, Transmissive |
| cúlsolas | 7S2P WLED , 30K hours , No Driver |
| a úsáidtear le haghaidh | Industrial |
| scáileán tadhaill | Without |
| G070VTN01.0 | AUO | 7.0 | 800×480 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| G070VW01 V0 | AUO | 7.0 | 800×480 |
| G070VW01 V1 | AUO | 7.0 | 800×480 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TX18D40VM1CAA | KOE | 7.0 | 800×480 |
