| Uimhir Pháirt | DLC0500HZG-T-8 |
| Branda | Other |
| Méid | 5.0 |
| Iarratas | PND |
| Rún | 800×480 |
| Comhdhéanamh | LCM |
| Gile | 640 |
| CR | 500:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | TTL |
| branda painéil | DLC |
| múnla painéil | DLC0500HZG-T-8 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 5.0 inch |
| taifeach | 800(RGB)×480 , WVGA |
| mód taispeána | TN, Normally White, Transmissive |
| limistéar gníomhach | 108×64.8 mm |
| imlíne | 120.7×75.8×4.5 mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 640 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (8-bit), CIE193150% |
| am freagartha | 20 (Typ.)(Tr+Td) |
| uillinn féachana | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 10S2PWLEDWithout Driver |
| comhéadan comhartha | Parallel RGB (1 ch, 8-bit), 40 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | PND |
