| Uimhir Pháirt | DLC0066ANOG-Y |
| Branda | Other |
| Méid | 0.66 |
| Iarratas | |
| Rún | 64×48 |
| Comhdhéanamh | OLED |
| Gile | 150 |
| CR | 2000:1 |
| Dathanna | Mono(Yellow) |
| Cúlsolas | self |
| Comhéadan | CPU/SPI/I²C |
| branda painéil | DLC |
| múnla painéil | DLC0066ANOG-Y |
| cineál painéil | PM-OLED , OLED |
| méid an phainéil | 0.66 inch |
| taifeach | 64×48 |
| limistéar gníomhach | 13.42×10.06 mm |
| imlíne | 18.46×18.1×1.55 mm |
| dromchla | |
| gile | 150 cd/m² (Typ.) |
| cóimheas codarsnachta | 2000 : 1 (Min.) |
| dathanna a thaispeáint | Mono(Yellow) (1-bit) |
| uillinn féachana | 80/80/80/80 (Min.)(L/R/U/D) |
| Tiománaí ic | COG Built-in SSD1306 |
| comhéadan comhartha | 8-bit 6800/8080 parallel, 4-wire SPI, I²C, 28 pins |
| voltas ionchuir | 2.8/9.0V (Typ.)(VDD/VCC) |
