| Uimhir Pháirt | CLAA080WQ05 XN |
| Branda | CPT |
| Méid | 8.0 |
| Iarratas | Pad & Tablet Industr |
| Rún | 800×1280 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 3S7P |
| Comhéadan | |
| monaróir | CPT |
| méid scáileáin | 8.0 inch |
| uimhir picteilín | 800(RGB)×1280 (WXGA) 188PPI |
| limistéar gníomhach(mm) | 107.64 × 172.224 (H×V) |
| limistéar bezel (mm) | - |
| luminance | 350 (Typ.)(cd/m²) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M 58% NTSC |
| mais | 115g (Max.) |
| ráta athnuachana | 60Hz |
| ainm samhail | CLAA080WQ05 XN |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Vertical Stripe |
| imlíne (mm) | 114.6 × 184.7 × 4.56 (H×V×D) |
| cóireáil | Hard coating (3H) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| modh oibre | HFFS, Normally Black, Transmissive |
| freagra | 30 (Typ.)(Tr+Td) ms |
| cúlsolas | 3S7P WLED , 15K hours , No Driver |
| a úsáidtear le haghaidh | Pad & Tablet Industrial |
| scáileán tadhaill | Without |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
