| Uimhir Pháirt | CLAA080WK02 XN |
| Branda | CPT |
| Méid | 8.0 |
| Iarratas | Automotive Display |
| Rún | 1280×720 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | CPT |
| Mionsamhail | CLAA080WK02 XN |
| méid trasnánach | 8.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1280(RGB)×720 [WXGA] 183PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 177.024(H)×99.576(V) mm |
| imlíne dim. | 186.5(H)×117.22(V) ×13.1(D) mm |
| limistéar bezel | 179.03(H)×101.58(V) mm |
| cóireáil | Antiglare (Haze 25%) |
| luminance | 600 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| treo amharc | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| modh oibriúcháin | HFFS, Normally Black, Transmissive |
| dath tacaíochta | 262K/16.7M 70% NTSC |
| foinse solais | WLED [5S4P] , 30K hours , W/O Driver |
| meáchan | TBD |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| soláthar leictreachas | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
