| Uimhir Pháirt | C084SAT01.1 |
| Branda | AUO |
| Méid | 8.4 |
| Iarratas | Automotive Display |
| Rún | 800×600 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 1000:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| monaróir | AUO |
| méid scáileáin | 8.4 inch |
| uimhir picteilín | 800×600(RGB) (SVGA) 118PPI |
| limistéar gníomhach(mm) | 170.88 × 128.16 (H×V) |
| luminance | - |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| radharc maith ag | Symmetry |
| doimhneacht dath | 16.7M |
| mais | - |
| ráta athnuachana | 60Hz |
| uas. rátálacha | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 90 °C |
| ainm samhail | C084SAT01.1 |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| socrú | RGB Horizontal Stripe |
| imlíne (mm) | - |
| cóimheas codarsnachta | 1000 : 1 (Typ.) (TM) |
| freagra | 15/20 (Typ.)(Tr/Td) ms |
| modh oibre | AHVA, Normally Black, Transmissive |
| cúlsolas | WLED , No Driver |
| a úsáidtear le haghaidh | Automotive Display |
| scáileán tadhaill | Without |
