| Uimhir Pháirt | BP101WX1-300 |
| Branda | BOE |
| Méid | 10.1 |
| Iarratas | PAD |
| Rún | 1280×800 |
| Comhdhéanamh | LCM |
| Gile | 450 |
| CR | 900:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | BOE |
| múnla painéil | BP101WX1-300 5 Compatible model |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 10.1 inch |
| taifeach | 1280(RGB)×800 , WXGA |
| mód taispeána | ADS, Normally Black, Transmissive |
| limistéar gníomhach | 216.96×135.6 mm |
| imlíne | 228.21×148.86×4.59 mm |
| dromchla | Hard coating (3H), Antireflection |
| gile | 450 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (6-bit + Hi-FRC), CIE193153% |
| am freagartha | 25 (Typ.)(Tr+Td) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | 4 stringsWLEDWithout Driver |
| comhéadan comhartha | LVDS (1 ch, 8-bit), 45 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | PAD |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| BP101WX1-200 | BOE | 10.1 | 1280×800 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| BP101WX1-300 | BOE | 10.1 | 1280×800 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| EJ101IA-01C | Innolux | 10.1 | 1280×800 |
| HE070IA-04M | Innolux | 7.0 | 800×1280 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| HV121WX4-120 | HYDIS | 12.1 | 1280×800 |
| LQ104X2LX05A | SHARP | 10.4 | 1024×768 |
| LTL101AL06-002 | Samsung | 10.1 | 1280×800 |
| PJ101IA-01A | Innolux | 10.1 | 1280×800 |
