| Uimhir Pháirt | B156HAB02.0 |
| Branda | AUO |
| Méid | 15.6 |
| Iarratas | Laptop |
| Rún | 1920×1080 |
| Comhdhéanamh | a-Si TFT-LCD, Assemb |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | eDP |
| branda painéil | AUO |
| múnla painéil | B156HAB02.0 |
| méid an phainéil | 15.6" |
| cineál painéil | a-Si TFT-LCD, Assembly |
| taifeach | 1920(RGB)×1080, FHD, 141PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 344.16(W)×193.59(H) mm |
| oscailt bezel | - |
| gile | - |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | - |
| radharc is fearr ar | Symmetry |
| am freagartha | 25 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 262K |
| cineál lampa | WLED , 15K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | On-Cell Touch |
| stíl cruth | - |
| iarratas | Laptop |
| comhéadan comhartha | eDP (2 Lanes) Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
