| Uimhir Pháirt | AV080WSM-NW2 |
| Branda | BOE |
| Méid | 8.0 |
| Iarratas | Automotive Display |
| Rún | 1024×600 |
| Comhdhéanamh | LCM, a-Si TFT-LCD |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | 3S10P |
| Comhéadan | LVDS |
| monaróir | BOE |
| ainm samhail | AV080WSM-NW2 |
| méid scáileáin | 8.0 inch |
| cineál scáileáin | LCM, a-Si TFT-LCD |
| uimhir picteilín | 1024(RGB)×600 (WSVGA) 148PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 176.64 × 99.36 (H×V) |
| imlíne (mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| limistéar bezel (mm) | 180.1 × 103.4 (H×V) |
| cóireáil | - |
| luminance | 600 cd/m² (Typ.) |
| cóimheas codarsnachta | 800 : 1 (Typ.) (TM) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| freagra | 25 (Typ.)(Tr+Td) ms |
| radharc maith ag | Symmetry |
| modh oibre | ADS, Normally Black, Transmissive |
| doimhneacht dath | 262K/16.7M 50% NTSC |
| cúlsolas | 3S10P WLED , 30K hours , No Driver |
| mais | 176/180g (Typ./Max.) |
| a úsáidtear le haghaidh | Automotive Display |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| soláthar voltais | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
