| Uimhir Pháirt | AT070WSM-NW2 |
| Branda | BOE |
| Méid | 7.0 |
| Iarratas | Automotive Display |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 262K/16.7M |
| Cúlsolas | WLED |
| Comhéadan | |
| branda | BOE |
| Mionsamhail | AT070WSM-NW2 |
| méid trasnánach | 7.0 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×600 [WSVGA] 170PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 154.214(H)×85.92(V) mm |
| imlíne dim. | - |
| luminance | - |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 25 (Typ.)(Tr+Tf) |
| uillinn féachana | 80/80/60/70 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K/16.7M 50% NTSC |
| foinse solais | WLED |
| meáchan | - |
| deartha le haghaidh | Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
