| Uimhir Pháirt | AT070TN04 |
| Branda | Innolux |
| Méid | 7.0 |
| Iarratas | Automotive Display |
| Rún | 480×234 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 300:1 |
| Dathanna | Full |
| Cúlsolas | CCFL |
| Comhéadan | TFT |
| branda | Innolux |
| méid trasnánach | 7.0 inch |
| formáid picteilín | 480(RGB)×234 76PPI |
| limistéar gníomhach | 154.08(H)×86.58(V) mm |
| limistéar bezel | - |
| luminance | 500 cd/m² (Typ.) |
| treo amharc | 6 o'clock |
| uillinn féachana | 60/60/40/60 (Typ.)(CR≥10) |
| dath tacaíochta | Full color |
| meáchan | 160g (Typ.) |
| ráta fhráma | 60Hz |
| cineál comhéadan | TFT Specific Analog RGB , 26 pins FPC |
| soláthar leictreachas | 5.0/5.0/15.0/-10.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| timpeallacht | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| Mionsamhail | AT070TN04 |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 164.9(H)×100(V) ×6(D) mm |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 300:1 (Typ.) (TM) |
| am freagartha | 10/20 (Typ.)(Tr/Td) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| foinse solais | CCFL [1 pcs] , 10K hours , W/O Driver |
| deartha le haghaidh | Automotive Display |
| painéal tadhaill | Without |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| AT070TN07 V.A | Innolux | 7.0 | 480×234 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| AT070TN82 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN83 | Innolux | 7.0 | 800×480 |
| AT070TN84 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT070TN92 V.1 TP | Innolux | 7.0 | 800×480 |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| AT070TNA2 | Innolux | 7.0 | 1024×600 |
