| Uimhir Pháirt | AM-19201200B1TZQW-00-B |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1920×1200 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AMPIRE |
| méid trasnánach | 10.1 inch |
| formáid picteilín | 1920(RGB)×1200 [WUXGA] 224PPI |
| limistéar gníomhach | 216.806(H)×135.504(V) mm |
| limistéar bezel | - |
| luminance | 1000 cd/m² (Typ.) |
| treo amharc | Symmetry |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| dath tacaíochta | 16.7M 53% NTSC |
| meáchan | - |
| ráta fhráma | 60Hz |
| cineál comhéadan | LVDS (2 ch, 8-bit) , 40 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| Mionsamhail | AM-19201200B1TZQW-00-B |
| cineál | a-Si TFT-LCD , LCM |
| cumraíocht | RGB Vertical Stripe |
| imlíne dim. | 243.45(H)×155.2(V) ×9.61(D) mm |
| cóireáil | Antiglare |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| am freagartha | 25 (Typ.)(Tr+Td) |
| modh oibriúcháin | Normally Black, Transmissive |
| foinse solais | WLED , 50K hours , With LED Driver |
| deartha le haghaidh | Industrial Outdoor High Brightness |
| painéal tadhaill | Without |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| HSD100IFW4-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
