| Uimhir Pháirt | B101UAN01.9 |
| Branda | AUO |
| Méid | 10.1 |
| Iarratas | PAD |
| Rún | 1920×1200 |
| Comhdhéanamh | LCM |
| Gile | 400 |
| CR | 600:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | AUO |
| múnla painéil | B101UAN01.9 |
| cineál painéil | a-Si TFT-LCD , LCM |
| méid an phainéil | 10.1 inch |
| taifeach | 1920(RGB)×1200 , WUXGA |
| mód taispeána | AHVA, Normally Black, Transmissive |
| limistéar gníomhach | 216.81×135.5 mm |
| imlíne | 242.44×148.15×4.7 mm |
| dromchla | Antiglare |
| gile | 400 cd/m² (Typ.) |
| cóimheas codarsnachta | 600:1 (Typ.) |
| dathanna a thaispeáint | 16.7M (6-bit + Hi-FRC), CIE193152% |
| am freagartha | 15/10 (Typ.)(Tr/Td) |
| uillinn féachana | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| minicíocht | 60Hz |
| cineál lampa | WLEDEmbedded (LED Driver) |
| comhéadan comhartha | LVDS (2 ch, 8-bit), 50 pins |
| voltas ionchuir | 3.3V (Typ.) |
| iarratas | PAD |
