| Uimhir Pháirt | AM-1280800P4TZQW-T11H |
| Branda | AMPIRE |
| Méid | 7.0 |
| Iarratas | Industrial |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 6S4P |
| Comhéadan | |
| branda painéil | AMPIRE |
| méid an phainéil | 7.0" |
| taifeach | 1280(RGB)×800, WXGA, 217PPI |
| limistéar taispeána | 149.76(W)×93.6(H) mm |
| méid imlíne | 162.3(W)×107.9(H) ×11.8(D) mm |
| gile | 850 cd/m² (Typ.) |
| uillinn féachana | 80/80/80/80 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 50% NTSC |
| minicíocht | 60Hz |
| meáchan | - |
| múnla painéil | AM-1280800P4TZQW-T11H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 152.76(W)×96.6(H) mm |
| dromchla | - |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | SFT, Normally Black, Transmissive |
| am freagartha | 35 (Typ.)(Tr+Td) |
| cineál lampa | 6S4P WLED , 50K hours , With LED Driver |
| scáileán tadhaill | PCAP |
| iarratas | Industrial |
