| Uimhir Pháirt | AM-1280800NGTZQW-17H |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S6P |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| méid an phainéil | 10.1" |
| taifeach | 1280(RGB)×800, WXGA, 149PPI |
| limistéar taispeána | 216.96(W)×135.6(H) mm |
| méid imlíne | 231(W)×154.4(H) ×6.2(D) mm |
| gile | 1500 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 45% NTSC |
| minicíocht | 60Hz |
| meáchan painéal | TBD |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 40 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| múnla painéil | AM-1280800NGTZQW-17H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 220.76(W)×140.4(H) mm |
| dromchla | Hard coating |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | IPS, Normally Black, Transmissive |
| am freagartha | 25 (Typ.)(Tr+Td) |
| cineál lampa | 7S6P WLED , 50K hours , Without Driver |
| scáileán tadhaill | Without |
| iarratas | Industrial Outdoor High Brightness |
