| Uimhir Pháirt | AM-1280800N2TZQW-T28H |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial Outdoor H |
| Rún | 1280×800 |
| Comhdhéanamh | a-Si TFT-LCD , LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | 7S6P |
| Comhéadan | |
| branda painéil | AMPIRE |
| méid an phainéil | 10.1" |
| taifeach | 1280(RGB)×800, WXGA, 149PPI |
| limistéar taispeána | 216.96(W)×135.6(H) mm |
| méid imlíne | 247(W)×166(H) ×8.95(D) mm |
| gile | 850 cd/m² (Typ.) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| radharc is fearr ar | Symmetry |
| dathanna a thaispeáint | 16.7M 45% NTSC |
| minicíocht | 60Hz |
| meáchan | 413g (Typ.) |
| múnla painéil | AM-1280800N2TZQW-T28H |
| cineál painéil | a-Si TFT-LCD , LCM |
| formáid picteilín | RGB Vertical Stripe |
| oscailt bezel | 220.76(W)×140.4(H) mm |
| dromchla | - |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| mód taispeána | IPS, Normally Black, Transmissive |
| am freagartha | 25 (Typ.)(Tr+Td) |
| cineál lampa | 7S6P WLED , 50K hours , Without Driver |
| scáileán tadhaill | PCAP |
| iarratas | Industrial Outdoor High Brightness |
| AM-1280800N1TZQW-T06H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| G101STN01.2 | AUO | 10.1 | 1024×600 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| LTN101NT02-L01 | Samsung | 10.1 | 1024×600 |
| M101NWWB R8 | IVO | 10.1 | 1280×800 |
| VVX10F008B00 | Panasonic | 10.1 | 1920×1200 |
