| Uimhir Pháirt | AM-1024768Y2TZQW-A1H |
| Branda | AMPIRE |
| Méid | 10.4 |
| Iarratas | Industrial Outdoor H |
| Rún | 1024×768 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 900:1 |
| Dathanna | 16.2M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| múnla painéil | AM-1024768Y2TZQW-A1H |
| méid an phainéil | 10.4" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1024(RGB)×768, XGA, 123PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 211.2(W)×158.4(H) mm |
| oscailt bezel | 213.2(W)×160.4(H) mm |
| méid imlíne | 236(W)×174.3(H) ×10.4(D) mm |
| dromchla | Antiglare, Hard coating (3H) |
| gile | 1000 cd/m² (Typ.) |
| cóimheas codarsnachta | 900:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | IPS, Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 30 (Typ.)(Tr+Td) |
| dathanna a thaispeáint | 16.2M |
| cineál lampa | WLED , 30K hours , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | TBD |
| iarratas | Industrial Outdoor High Brightness |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 20 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| G104SN03 V4 | AUO | 10.4 | 800×600 |
| LM10V332R | SHARP | 10.4 | 640×480 |
| LTD104KA1S | TOSHIBA | 10.4 | 1024×768 |
| LTM10C209A | TOSHIBA | 10.4 | 640×480 |
| NL6448BC33-50 | NLT | 10.4 | 640×480 |
| NL6448BC33-63D | NLT | 10.4 | 640×480 |
