| Uimhir Pháirt | AM-1024600Y3TZQW-A0H |
| Branda | AMPIRE |
| Méid | 9.0 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 800:1 |
| Dathanna | 16.7M |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda painéil | AMPIRE |
| múnla painéil | AM-1024600Y3TZQW-A0H |
| méid an phainéil | 9.0" |
| cineál painéil | a-Si TFT-LCD, LCM |
| taifeach | 1024(RGB)×600, WSVGA, 132PPI |
| formáid picteilín | RGB Vertical Stripe |
| limistéar taispeána | 196.6(W)×114.1(H) mm |
| oscailt bezel | 200(W)×117.55(H) mm |
| méid imlíne | 211.1(W)×126.5(H) ×11(D) mm |
| dromchla | - |
| gile | 500 cd/m² (Typ.) |
| cóimheas codarsnachta | 800:1 (Typ.) (TM) |
| uillinn féachana | 85/85/85/85 (Typ.)(CR≥10) |
| mód taispeána | Normally Black, Transmissive |
| radharc is fearr ar | Symmetry |
| am freagartha | 18/17 (Typ.)(Tr/Td) |
| dathanna a thaispeáint | 16.7M |
| cineál lampa | WLED , With LED Driver |
| minicíocht | 60Hz |
| scáileán tadhaill | Without |
| meáchan painéal | TBD |
| iarratas | Industrial |
| comhéadan comhartha | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltas ionchuir | 3.3V (Typ.) |
| timpeallacht | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
