| Uimhir Pháirt | AM-1024600LHMQW-16H |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial |
| Rún | 1024×600 |
| Comhdhéanamh | LCM , a-Si TFT-LCD |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | 6S6P |
| Comhéadan | LVDS |
| monaróir | AMPIRE |
| ainm samhail | AM-1024600LHMQW-16H |
| méid scáileáin | 10.1 inch |
| cineál scáileáin | LCM , a-Si TFT-LCD |
| uimhir picteilín | 1024(RGB)×600 (WSVGA) 117PPI |
| socrú | RGB Vertical Stripe |
| limistéar gníomhach(mm) | 222.72 × 125.28 (H×V) |
| imlíne (mm) | 235 × 145.8 × 7.3 (H×V×D) |
| limistéar bezel (mm) | 225.92 × 128.48 (H×V) |
| cóireáil | Antiglare |
| luminance | 250 cd/m² (Typ.) |
| cóimheas codarsnachta | 500 : 1 (Typ.) (TM) |
| uillinn féachana | 70/70/70/50 (Typ.)(CR≥10) |
| freagra | 4/12 (Typ.)(Tr/Td) ms |
| radharc maith ag | - |
| modh oibre | TN, Normally White, Transmissive |
| doimhneacht dath | 262K 47% NTSC |
| cúlsolas | 6S6P WLED , 20K hours , With LED Driver |
| mais | TBD |
| a úsáidtear le haghaidh | Industrial |
| ráta athnuachana | 60Hz |
| scáileán tadhaill | Without |
| cineál comhartha | LVDS (1 ch, 6-bit) , 30 pins Connector |
| soláthar voltais | 3.3V (Typ.) |
| uas. rátálacha | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
