| Uimhir Pháirt | AM-1024600L3HMQW-00H |
| Branda | AMPIRE |
| Méid | 10.1 |
| Iarratas | Industrial Automotiv |
| Rún | 1024×600 |
| Comhdhéanamh | a-Si TFT-LCD, LCM |
| Gile | |
| CR | 500:1 |
| Dathanna | 262K |
| Cúlsolas | WLED |
| Comhéadan | LVDS |
| branda | AMPIRE |
| Mionsamhail | AM-1024600L3HMQW-00H |
| méid trasnánach | 10.1 inch |
| cineál | a-Si TFT-LCD, LCM |
| formáid picteilín | 1024(RGB)×600 [WSVGA] 117PPI |
| cumraíocht | RGB Vertical Stripe |
| limistéar gníomhach | 222.72(H)×125.28(V) mm |
| imlíne dim. | 235(H)×145.8(V) ×8.85(D) mm |
| limistéar bezel | - |
| cóireáil | Antiglare |
| luminance | 550 cd/m² (Typ.) |
| cóimheas codarsnachta | 500:1 (Typ.) (TM) |
| treo amharc | - |
| am freagartha | 4/12 (Typ.)(Tr/Td) |
| uillinn féachana | 70/70/70/50 (Typ.)(CR≥10) |
| modh oibriúcháin | TN, Normally White, Transmissive |
| dath tacaíochta | 262K 47% NTSC |
| foinse solais | WLED [6S6P] , 30K hours , With LED Driver |
| meáchan | TBD |
| deartha le haghaidh | Industrial Automotive Display |
| ráta fhráma | 60Hz |
| painéal tadhaill | Without |
| cineál comhéadan | LVDS (1 ch, 8-bit) , 30 pins Connector |
| soláthar leictreachas | 3.3V (Typ.) |
| timpeallacht | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| LP101WSA-TLN1 | LG Display | 10.1 | 1024×600 |
| M101MWW4 R0 | IVO | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
